H03VVH2-F PVC Flat Cable

Rated voltage: 300/300 V
Standard: EN 50525-2-11
Temperature range: -5°C to +60°C
Flame retardant: IEC 60332-1-2

Ships within 3–5 business days, subject to prior ex-stock sales
Available in 2 sizes. See the size table
Custom lengths cut to order
Need help choosing? Call +65 6747 3336

About H03VVH2-F PVC Flat Cable

H03VVH2-F is a flexible PVC flat cable resistant to flame and light mechanical stress. It is suitable for use indoor and dry conditions. Installation is apt for household and office appliances. For example, hair dryers, desk lamps, radios, etc.

Construction

Conductor	Flexible fine copper wires according to IEC 60228 Class 5
Insulation	PVC compound TI2 quality according to EN 50363-3
Outer sheath	Flat PVC compound TM2 quality according to EN 50363-4-1

Electrical

Rated voltage	300/300 V
Test voltage	1500 V

Thermal and mechanical

Temperature range	-5°C to +60°C
Max conductor temperature	70°C
Min bending radius	6 x D (outer diameter)

Resistance

Flame retardant	according to IEC 60332-1-2

Standards and compliance

Standard	EN 50525-2-11

Sizemm²	Goldberg no.	Insulationmm	Overall diametermm	Conductor resistance at 20°CΩ/km	Current rating at 30°CA	Quote
2 x 0.5	GB22005	0.5	2.7 x 4.6 – 3.6 x 5.6	39.0	3	Quote
2 x 0.75	GB22075	0.5	2.9 x 5.1 – 3.9 x 6.1	26.0	6	Quote

Values from the Goldberg datasheet and indicative only. Full drums: final length may vary −0% to +10% from the length ordered; lengths cut to order are supplied as ordered.
