Construction
Conductor
Flexible fine copper wires according to IEC 60228 Class 5
Insulation
Cross-linked halogen-free rubber compound EI8 according to EN 50363-5
Outer sheath
Cross-linked halogen-free rubber compound EM8 according to EN 50363-6
Electrical
Rated voltage
450/750 V
Fixed and protected installation
600/1000 V
Test voltage
2500 V
Current rating
according to EN 50565-1 Table C.2 (ambient 30°C, conductor 60°C)
Thermal and mechanical
Temperature range
-40°C to +90°C (fixed), -5°C to +90°C (occasional flexing)
Max conductor temperature
90°C
Short-circuit temperature
250°C (max. 5 s)
Max tensile load
15 N/mm² (max. 1000 N)
Min bending radius
4 to 8 x D (outer diameter) according to EN 50565-1
Resistance
Flame retardant
according to EN 60332-1-2; no fire propagation according to EN 60332-3-24
Low smoke zero halogen
Halogen-free according to EN 50525-1 Annex B; low corrosive gases according to EN 60754-2; smoke density according to EN 61034-2 (>60% light transmittance)
Values from the Goldberg datasheet and indicative only. Full drums: final length may vary −0% to +10% from the length ordered; lengths cut to order are supplied as ordered.
